When it pertains to the application of plastic CNC products or material, thickness enters a factor to consider. If you can’t discover a means to convert plastic film density gauge in between Mil, MM, and also other units, please examine the plastic scale density graph as well as calculation formula at the following.

What is Plastic Gauge Thickness?

The thickness of plastic movie or sheet is frequently described as Gauge, or shared in Mil, which is equal to a thousand of an inch. To grasp as well as reveal the thickness of plastic products properly in any kind of areas and times, there is a plastic scale thickness graph to help you relocate between these units.

Plastic Gauge Thickness Graph

The conversion partnership between these thickness systems is: a Mil is 1000 times of an inch, the Gauge is (100) x (Mils), To go from Mils to Microns, you multiply mils x 25.4. So the calculation formulas for plastic gauge are as below.
Mil = 1000 x Inch
Micron = Mil x 25.4
Micron = Gauge x 0.254
Scale = 100 x Mil
Scale = Micron x 3.937
You can also choose the Plastic film thickness calculator to obtain the outcome quicker.
Here is the plastic gauge thickness conversion chart, you can inspect some data directly. The plastic scale is different from the wire scale for plastic scale measurement, the larger the scale, the thicker the movie.
Keep in mind:

  • Gauge is generally scheduled for thicknesses listed below 1 mil.
  • Mil is a US unit of measurement as well as Micron (um or Micrometer) is a metric system measurement of thickness.
  • Microns measurements are usually rounded to the nearest whole integer. 7.62 microns is typically revealed in 7.6.
  • When working with flexible obstacle plastics, mil to Micron conversion is generally the most important conversion to make.
Gauge Mil Micron Millimetre Inch
30 0.30 7.6 0.0076 0.0003
35 0.35 8.9 0.0089 0.00035
40 0.40 10.2 0.0102 0.0004
45 0.45 11.4 0.0114 0.00045
50 0.50 12.7 0.0127 0.0005
55 0.55 14.0 0.0140 0.00055
60 0.60 15.2 0.0152 0.0006
65 0.65 16.5 0.0165 0.00065
70 0.70 17.8 0.0178 0.0007
75 0.75 19.1 0.0191 0.00075
80 0.80 20.3 0.0203 0.0008
90 0.90 22.9 0.0229 0.0009
100 1.00 25.4 0.0254 0.001
110 1.10 27.9 0.0279 0.0011
120 1.20 30.5 0.0305 0.0012
130 1.30 33.0 0.0330 0.0013
140 1.40 35.6 0.0356 0.0014
150 1.50 38.1 0.0381 0.0015
160 1.60 40.6 0.0406 0.0016
170 1.70 43.2 0.0432 0.0017
180 1.80 45.7 0.0457 0.0018
190 1.90 48.3 0.0483 0.0019
200 2.00 50.8 0.0508 0.002
300 3.00 76.2 0.0762 0.003
